Origin Live Calypso MKV Turntable

SKU: 53218 Category: Availability: Within 10 working days

3.700,00

The Origin Live Calypso MKV Turntable combines advanced features like the Mk5 Motor Power Supply for exceptional speed stability, a DC100 Motor for smooth operation, and a high-grade belt for enhanced dynamics. It features an ultra-low friction bearing, high specification sub-chassis, and unique suspension system to minimize vibration and improve sound clarity. With its superb styling and comprehensive inertia discs, the Calypso MKV delivers unparalleled audio performance and a striking aesthetic. A high end turntable made for discerning audiophiles.

Available on backorder

Feel Safe Paying With

Description

Origin Live Calypso MKV Turntable

Features

Mk5 Motor Power Supply

The Origin Live Calypso features the Mk5 Motor Power Supply which introduces a new PCB in the PSU on all decks offering even more speed stability and improved sonic performance than the former Light Speed Controller. Common problems like speed drift, motor jitter and cogging are avoided. Speed settings for 33.33 and 45 RPM are operated through one knob with no need for belt/platter change.

DC100 Motor

These high-grade Swiss motors demonstrate the powerful, smooth-running needed in a good turntable motor. Ironless cores eliminate eddy currents which result in low “clogging”, low vibration and speed stability. Motors are decoupled to minimize vibration and reduce audible noise.

Belt

The belt is manufactured in house using special material which increases grip and reduces stretch under instantaneous loading, using a unique material which dramatically improves on widely used neoprene rubber – benefits include increased dynamics and deeper bass performance.

origin live calypso pod

hifi choice award
hifi world award
the ear award

High Specification Power Supply

Carefully selected cables from premium suppliers are attached to motor circuitry that is designed to ensure the motor, the platter and your vinyl are running smoothly on a consistent power supply.

Pulley

A well researched special plastic pulley enables maximum belt grip, resulting in increased definition and dynamics.

Standard Armboard

Our standard armboard provides premium performance for the price point. Decoupled from the rest of the turntable, the armboard is balanced in equilibrium with the platter and bearing house.

Origin Live Calypso Armboard

Ultra-low Friction Bearing

Made in house, the new MK4 bearing has ultra low levels of vibration. The spindle rotates on a Tungsten carbide ball bearing centered on a hardened thrust pad for low friction and long life. Low bearing friction is essential to avoid vibration. Unlike decks which “float” the platter using air or magnetic bearings, we believe “earthing” the energy out of the platter is essential for sound purity.

Suspension

Our unique suspension avoids both the softening of leading edges often found in suspended designs and the hardness in many non-suspended designs. The results are:

  • Superior pitch, rhythm, and timing
  • Rock-solid imaging
  • Reduced colouration
  • Refined presentation of low-level information
  • Easy to follow separation in the music and vocals

High Specification Sub-Chassis

The sub-chassis plate balances the armboard with the platter and bearing house, decoupling both from the turntable plinth. Its mass heavy design also helps to effectively damp vibration travelling through the armboard and platter.

Heavy Inertia Disc

Pictured here beneath the arm board and platter, this stainless steel disc adds a large mass to the plinth, greatly reducing resonance. Placed at the point of its connection to the sub-chassis, this weighs down the plinth, effectively reducing vertical modes of vibration traveling across the plinth and into the sub-chassis. This minimizes any vibration that could travel into the platter or arm board to disturb your vinyl.

Front Loading Inertia Discs x 2

As well as the heavy inertia disc, these smaller inertia discs are positioned at the extremities of the plinth, where the plinth may be susceptible to vibration. The small inertia discs resist rotational forces arising from ground and airborne vibration. This maintains the plinths equilibrium and in turn the equilibrium of the whole turntable.

Suberb Styling

The Calypso’s circular forms evoke curving mid-century designs. The unmistakable profile and black polished finish make it an eye-catching asset for any decor.

REVIEWS FOR THE ORIGIN LIVE CALYPSO

“The Calypso Multilayer/Silver proves a really impressive performer. It has a big, spacious sound that’s strong on dynamics, involvement and tonal purity, with excellent detail retrieval.” Read the Full Review >
Hi-Fi Choice

“It is still a relatively modest package, yet it produced some of the very best sounds from vinyl that I have heard for a considerable while……. An Audio Excellence rating is amply deserved.” Read the full review >
Hi-Fi Critic

“…It will come as no surprise that I am totally smitten with this player. It is a permanent part of my system and I seriously doubt if there is a player out there that can beat it in terms of outright enjoyment and musical flow. And even in technical and audiophile terms, I’ve not heard a better performance than this.” Read the full review >
Hi-Fi Advice, Christiaan Punter


High Performance Turntables Produce the Ultimate Sound Quality

The record player still reigns supreme in terms of performance. Experts agree that leading turntables provide a more satisfying musical experience than any digital counterparts. Unlike digital streaming & CD, there seems no limitation on the musical information that turntables can extract from vinyl. In recent years, advances in some turntables have caused the gulf between digital performance and vinyl to widen even further. Origin Live draws together many long-established principles of high-end turntable design, along with advanced innovations, to reveal just how much the vinyl medium is capable of.

Why invest in a quality turntable?

If you are unfamiliar with Hi-Fi you may be unaware of the major sound quality differences between one turntable and another. There are over 800 different decks on the market. Faced with such a colossal choice, many buyers take the shortcut and assume “if it looks good, and has a good review, it must be good”. Unfortunately, nothing could be further from the truth. To its credit, the Hi-Fi press has long extolled the importance of a good turntable for high sound quality. If the source signal is degraded in the first place, everything else in the Hi-Fi Chain can only exaggerate the problem. It is important to choose your turntable based on its sound quality, which comes from its engineering and design.

Here at Origin Live, we make almost all of our components in our own workshop in the UK, this means we are in total control of the materials, quality control, and design of our products. You won’t find any chipboard, plywood, or flimsy components in these turntables. Using mass effective design in our bearing houses, plinths, arm boards and platters, all possible areas where jitter and vibration can be removed have been carefully considered. Through relentless development, we have selected materials that produce the natural, uninhibited tone from your vinyl.

Turntable Differences Are Greater Than Any Other Item Of Hi-Fi Equipment

CD players sound different to one another, but not a lot in comparison to turntables. Turntables have more influence on the sound of a system than almost any other item of Hi-Fi equipment and the differences between them are massive. A better turntable will improve the clarity, dynamics and ability to follow every strand of the music plus other aspects too numerous to mention. Gone is blurred, woolly bass and general confusion in the sound. Better turntables also have increased pitch stability adding a sense of sub-conscious sense of rhythm, security and confidence to your listening experience.

Rewards Of Higher Investment

A cheap £165 turntable will fall well short of CD performance, whereas a good £1500 turntable should outperform CD. The pursuit of the ultimate sound goes well beyond CD quality however. Turntables can improve a lot further with the right choices in equipment, and often this involves higher investment.

No one could blame you for being sceptical that a truly high-performance turntable is worth the investment. It’s usually only by hearing a direct comparison between two similar-looking decks, that the penny drops. The difference in musical cohesion, dynamics and ability to follow music effortlessly is simply jaw-dropping. It leaves one wondering how such massive differences can possibly exist when outward appearances can look so similar. Usually, this is down to materials, design and engineering. We explain further in our article: what makes the best turntable.

The conclusion is that it’s worth hearing turntable differences so you know what’s possible in terms of sound quality.

Specifications

Features of Origin Live Turntables

TURNTABLE Aurora Calypso Resolution Sovereign Voyager
Multi-layer Platter
No No No Yes Yes
High Performance Armboard No No Yes Yes Yes
Motor
DC100 DC100 DC100 DC100 DC100 x 2
Sub-Chassis Inertia Disc No Yes Yes No No
Heavyweight Plinth
No No No Yes Yes
Maximum Decouping on Main Bearing
No No Yes Yes Yes
“Footprint” of deck & Minimum Dimensions of Support Surface (cm) (WxD) 40 x 29 40 x 29 40 x 29 40 x 29 40 x 37
Overall Size with 9.5 inch arm see top line (cm) (Width x Depth x Height)
For 12 inch arms use lower line
49x36x17
55x36x17
49x36x17
55x36x17
49x36x17
55x36x17
50x38x19
55x39x19
Weight (kg) 10.3 11.5 12.1 28.4
Shipping Dimensions (cm) (Width x Depth x Height)
60 x 45 x 16 60 x 45 x 16 60 x 45 x 16 60 x 50 x 30
Weight Packaged (kg) (Width x Depth x Height)
12 13.3 13.9 32
