Ferrum Audio HYPSOS Power Supply

Ferrum Audio HYPSOS Power Supply

High-End Hybrid DC Power Supply | 5-30V Adjustable Output | 4T Sensing Design | Sweet Spot Tuning

The Ferrum Audio HYPSOS Power Supply is a high-end hybrid power system engineered to provide exceptionally precise, stable and flexible DC power for compatible audio components.

Combining the advantages of linear and switching power supply technologies, Ferrum HYPSOS introduces an innovative approach to powering DACs, headphone amplifiers, network streamers and other high-performance audio devices.

Rather than functioning as a conventional external power adapter, the HYPSOS has been designed as a dedicated audio component with advanced voltage regulation, intelligent control and extensive protection features.

Its distinctive technologies include Sweet Spot Tuning (SST), 4-Terminal Sensing Design (4TSD), Automatic Transformer Voltage Adjust (ATVA) and electronically controlled output polarity.

Available through Chameleon Audio, the Ferrum HYPSOS provides a flexible power supply upgrade for carefully matched high-end audio systems.

Why Power Supply Quality Matters in High-End Audio

Power supply performance is an important part of audio system engineering. Sensitive digital and analogue audio circuits depend on correctly regulated supply voltages and controlled electrical noise.

Voltage stability, output impedance, ripple, transient response and the interaction between a power supply and its connected device can influence overall circuit performance.

The Ferrum HYPSOS addresses these considerations through its hybrid architecture, active voltage regulation and dedicated sensing system.

The audible result depends on the connected equipment and its original power supply design, but HYPSOS provides an advanced platform for investigating the benefits of improved DC power delivery.

Ferrum HYPSOS: Hybrid Power System

Adjustable 5-30V DC Output

One of the most important features of the Ferrum HYPSOS Power Supply is its electronically adjustable output voltage.

HYPSOS supports a regulated DC output range of 5V to 30V, allowing it to power a wide range of compatible audio devices.

Users can select a supported product from the built-in device configuration list or enter the required electrical parameters manually.

The system guides the user through confirmation of the voltage and polarity settings before enabling the output.

This flexibility means HYPSOS can potentially be used with several different audio components over time, provided their electrical specifications, connector requirements and power consumption are compatible.

Output Current and Power Capabilities

HYPSOS provides a maximum continuous output current of 6A for voltages below approximately 13.3V.

At higher output voltages, the continuous output power is limited to 80W, and the available continuous current decreases accordingly.

The maximum specified impulse current is 9A, subject to the manufacturer’s operating conditions.

Important: Compatibility must be assessed using the continuous output ratings, not only the maximum impulse figures.

Sweet Spot Tuning (SST)

Fine-Tune the Power Supply Voltage

Ferrum’s proprietary Sweet Spot Tuning (SST) technology allows users to fine-tune the output voltage within the permissible operating range of a compatible audio component.

This provides the possibility of evaluating different supply voltage settings while listening to the connected system.

For example, equipment designed to accept an approved voltage range may respond differently to changes within that range.

HYPSOS allows these settings to be adjusted through its electronic control interface without repeatedly disconnecting and replacing power supplies.

Safety note: Voltage adjustments must remain strictly within the range authorised by the manufacturer of the connected equipment. HYPSOS does not make it safe to exceed the device’s electrical ratings.

4-Terminal Sensing Design (4TSD)

The Ferrum HYPSOS 4T Sensing Design is one of the technologies that distinguishes it from many conventional DC power supplies.

Standard power supplies generally regulate voltage at their own output terminals. Voltage drop can occur across the connecting cable because of its electrical resistance.

Ferrum’s 4TSD architecture uses additional sensing conductors to monitor the voltage closer to the input of the connected audio component.

This feedback allows HYPSOS to compensate for voltage losses along the power cable, within the system’s operating limits.

The objective is to maintain a more precisely regulated supply voltage at the actual load rather than only at the power supply enclosure.

Unique Four-Wire DC Output Cable

The dedicated four-wire connection used by HYPSOS contains two conductors for power delivery and two additional conductors for voltage sensing.

The sensing wires provide feedback to the regulation circuit, allowing it to monitor voltage behaviour at the receiving component.

This architecture is especially relevant when current demand changes dynamically during equipment operation.

The 4T sensing functionality depends on a suitable cable and compatible connection arrangement.

Electronically Controlled Output Voltage and Polarity

Ferrum HYPSOS allows the output voltage and DC polarity to be configured electronically.

This expands compatibility with audio equipment that requires different DC voltage settings or connector polarities.

Before applying power, the system requests confirmation of the selected electrical configuration.

Correct polarity, voltage, connector dimensions and current capability must all be established before connection.

Never connect HYPSOS to equipment unless the full DC power requirements have been verified.

Automatic Transformer Voltage Adjust (ATVA)

Ferrum’s Automatic Transformer Voltage Adjust technology is another important element of the HYPSOS hybrid architecture.

The system manages transformer operating conditions as part of the overall power supply regulation strategy.

ATVA works alongside the electronic control architecture to support efficient operation across the adjustable DC voltage range.

Spread Spectrum Mode

Ferrum provides a Spread Spectrum Mode setting as part of the HYPSOS power supply control options.

This feature relates to the operation of the switching section and its electromagnetic interference characteristics.

Users can evaluate suitable operating settings according to the manufacturer’s instructions and the requirements of their audio system.

Advanced Protection and Operating Safety

HYPSOS incorporates several protective functions intended to reduce the risk of electrical problems during normal operation.

• Output overvoltage protection
• Current limiting
• Short-circuit protection
• Electronic output polarity control
• Confirmation before output activation
• Automatic Transformer Voltage Adjust
• Electronically controlled output settings

These safeguards supplement, but do not replace, the requirement to use the correct electrical settings for the connected component.

Advanced Automation and Remote Control

The Ferrum HYPSOS includes features for integration into more complex audio installations.

Trigger input and output connections allow power-control coordination with compatible equipment.

The system also supports selected Apple TV remote functions and automation possibilities for devices with suitable standby behaviour.

These features make HYPSOS an attractive choice for systems where coordinated power management is desirable.

Ferrum HYPSOS and Ferrum Power Link

Ferrum also offers its proprietary Ferrum Power Link (FPL) connection system for compatible Ferrum products.

Ferrum Power Link is intended to simplify power supply integration and provide the appropriate connection arrangement for supported components.

HYPSOS can be used with compatible equipment from the Ferrum ecosystem, including selected Ferrum audio components.

For a matching digital streaming transport, explore the Ferrum BROEN Network Streaming Transport.

Compatibility with DACs, Streamers and Audio Components

The Ferrum HYPSOS Hybrid Power Supply is designed for use with compatible audio equipment requiring an external DC power supply.

Potential applications include selected:

• Digital-to-analogue converters
• Network music streamers
• Digital audio transports
• Headphone amplifiers
• Phono preamplifiers
• Other compatible low-voltage audio components

HYPSOS is not universally compatible with every product in these categories.

Compatibility must be confirmed using the original manufacturer’s power requirements, DC polarity, connector dimensions and continuous current consumption.

Chameleon Audio can assist with checking whether Ferrum HYPSOS is suitable for your audio equipment and selecting the appropriate DC cable.

High-End Listening and Power Supply Optimisation

Ferrum designed HYPSOS as an audio power supply upgrade intended to help compatible equipment operate under carefully controlled electrical conditions.

Depending on the connected component, users may experience differences in perceived dynamics, tonal balance, background noise and presentation.

However, audible improvements are system-dependent and cannot be guaranteed for every compatible product.

For a meaningful comparison, users should evaluate the HYPSOS against their existing power supply under consistent listening conditions.

Professional Reviewer Comments

The Ferrum HYPSOS has received attention from specialist audio reviewers for its flexibility and influence on compatible audio systems.

“The Hypsos really did it. More dynamics, better bass performance…”

Morten Mohr & Marius Smolinski, Germany

“The Ferrum HYPSOS, is a game changer, not only as an improvement over the standard power supplies, but as a versatile addition to many DACs.”

David Robson, HiFi Pig, UK

These reviewer observations reflect their listening experiences with particular systems and should be considered alongside electrical compatibility and individual system requirements.

Ferrum HYPSOS Key Features

• High-end hybrid DC power supply
• Combined linear and switching design
• Adjustable 5V to 30V DC output
• Up to 6A continuous output current below approximately 13.3V
• Maximum continuous output power of 80W
• Maximum specified impulse current of 9A
• Sweet Spot Tuning (SST)
• 4-Terminal Sensing Design (4TSD)
• Dedicated four-wire DC output cable system
• Automatic Transformer Voltage Adjust (ATVA)
• Electronic DC output polarity selection
• Device presets and manual configuration
• Output voltage confirmation before activation
• Spread Spectrum Mode
• Overvoltage, current limit and short-circuit protection
• Trigger input and output
• Selected Apple TV remote compatibility
• Ferrum Power Link for compatible Ferrum equipment
• DC cable options for different connectors
• Software-controlled operation
• Premium compact chassis

Ferrum HYPSOS Technical Specifications

Specifications refer to the standard HYPSOS single-output power supply. The HYPSOS Dual Output is a separate model. Compatible cables and regional mains configurations should be confirmed when ordering.

Why Buy from Chameleon Audio?

At Chameleon Audio, we specialise in high-end audio systems, carefully selected components and expert system-matching advice.

Free Worldwide Shipping with Full Transport Insurance

All brand-new products purchased from Chameleon Audio include FREE SHIPPING WITH FULL TRANSPORT INSURANCE.

Your new audio equipment is carefully packed and insured during transportation for additional peace of mind.

Best Price Guarantee – Extra 10% Below

Found the same brand-new product at a lower price elsewhere?

Show us a verifiable lower-priced offer for the identical product, and Chameleon Audio will offer it at 10% BELOW that verified competitor price.

Simply contact us with the competing offer and supporting evidence. Once the product and lower price have been verified, we will prepare your personalised quotation.

Premium Hi-Fi. Fully Insured Free Shipping. Exceptional Value.

Frequently Asked Questions

What is the Ferrum HYPSOS?

Ferrum HYPSOS is a hybrid linear/switching DC power supply with adjustable output voltage, four-terminal sensing and advanced power regulation features.

What voltage range does HYPSOS support?

HYPSOS provides an adjustable DC output from 5V to 30V.

How much current can Ferrum HYPSOS deliver?

It supports up to 6A continuous output current below approximately 13.3V. Above that voltage, the maximum continuous current is limited by the 80W continuous power rating.

What is Sweet Spot Tuning?

Sweet Spot Tuning allows the output voltage to be adjusted within the connected device manufacturer’s permitted operating range for comparative evaluation.

What is Ferrum 4T Sensing Design?

4TSD uses separate voltage sensing conductors to monitor voltage at the receiving component and compensate for cable-related voltage drop.

Can I use HYPSOS with any DAC?

No. A DAC must have compatible external DC power requirements, correct polarity, suitable connector dimensions and an acceptable continuous current requirement.

Can HYPSOS power a network streamer?

Yes, provided the streamer supports an external DC supply compatible with HYPSOS. Compatible Ferrum devices may use Ferrum Power Link.

Can HYPSOS replace a 12V power supply?

Potentially, if the connected equipment requires compatible 12V DC power and all current, connector and polarity requirements are met.

Can changing the voltage damage my equipment?

Yes. Applying voltage outside the manufacturer’s permitted range can damage a connected component. Always verify and confirm the correct voltage settings before enabling the output.

Does HYPSOS support different connector sizes?

Yes. Ferrum provides different DC cable options, including 5.5 x 2.1mm and 5.5 x 2.5mm connections. Other compatible cables may be available separately.

What is Automatic Transformer Voltage Adjust?

ATVA is Ferrum’s transformer control technology used within the hybrid power supply architecture.

Does HYPSOS support automatic power control?

Yes. It provides trigger input and output connections and selected remote-control and automation functionality.

Is HYPSOS the same as HYPSOS Dual Output?

No. The standard HYPSOS is a single-output power supply. HYPSOS Dual Output is a separate model with additional output functionality.

Will Ferrum HYPSOS improve the sound of my DAC?

It may provide benefits in compatible systems, but audible results depend on the equipment, existing power supply design and system conditions.

Where can I buy Ferrum HYPSOS?

Ferrum HYPSOS is available through Chameleon Audio, with advice on device compatibility, power requirements and suitable DC cables.

Explore Ferrum at Chameleon Audio

For a complete Ferrum streaming front end, discover the Ferrum BROEN Network Streaming Transport.

Explore more high-end external power supply options in the Chameleon Audio Power Supplies collection.

For the latest technical information and official documentation, visit the Ferrum HYPSOS Official Manufacturer Page.

Ferrum Audio HYPSOS at Chameleon Audio

The Ferrum Audio HYPSOS Power Supply combines a sophisticated hybrid power architecture with precise voltage regulation, configurable output parameters and four-terminal voltage sensing.

With its adjustable 5-30V output range, Sweet Spot Tuning and extensive compatibility options, HYPSOS offers an advanced power supply solution for compatible high-end audio components.

Contact Chameleon Audio for device compatibility, cable selection, product availability and international delivery information.
