Canary Audio M608 Integrated Amplifier

SKU: 98539 Categories: , Availability: In Stock

7.100,00

The Canary Audio M608 Integrated Amplifier revives the award-winning CA-608 with modern upgrades. Outputting 40 Watts RMS with four EL34 tubes, a high voltage power supply, and custom hand-made transformers. Featuring a Japanese Alps volume control and multiple single-ended inputs, it offers precise control and connectivity. Handcrafted in California, it combines the best of power amplifiers and preamplifiers for unparalleled musical enjoyment.

Feel Safe Paying With

Description

Canary Audio M608 Integrated Amplifier

The Legend Continues

The award winning CA-608 was our very first integrated amplifier and since the day it launched, it soon became a big hit and was very well received by many audiophiles all around the world. The CA-608 was in production from June 1999 until November 2006. We had to discontinue the CA-608 because many of the original parts and components were out of production and no longer available.

Rebirth of the CA-608

We’ve received many requests for the CA-608 from time to time and we finally decided to it back to production. Based on the original CA-608, the M608 uses four EL34 output tubes in a modified circuitry and operates under ultra-linear mode. Like all of our other products, the M608 is built with the highest quality parts and components that we could ever find. The power and output transformers are hand made in the USA according to our specs. Swiss made ELMA rotary switch with gold-plated contacts is used as the input selector. Japanese Alps volume control pot is used for pricise volume adjusting.

The Prefect Combination

The M608 integrated amplifier is the result for the combination of our extraordinary designs in power amplifiers and preamplifiers. A combination that brings a new level of excitement and musical enjoyment.

Special Features

  • Rectifier with choke filtering.
  • Newly designed high voltage power supply.
  • Custom hand made power and output transformers.
  • Japanese Alps volume control pot.
  • Optional remote controlled volume.
  • Four pair of single-ended inputs with gold plated RCA jacks.
  • Military spec printed circuit boards with extra thick copper traces.
  • Advanced soft latching power on/off circuit with stainless steel push button switch.
  • 100% handcrafted in California, USA.

Specifications

Rated Power Output: 40 Watts RMS
Input Sensitivity: 1.0 Volts for full output
Input Impedance: 110,000 Ohms
Frequency Response: +/- 2dB from 10 Hz to 60,000 Hz
Total Harmonic Distortion: < 0.4%
Signal-to-Noise Ratio: -78 dB below 1 Watt
Damping Factor: 12
Power Consumption: 265 Watts (true RMS)
Output Impedance: 4, 8 Ohm
Tube Complement: 4 x EL34
2 x 6SN7
1 x 12AX7
Dimensions: 17.5″ W x 16.5″ D x 6.5″ H
Net Weight: 50 lbs
