CSPort TAT1M2 Turntable

Name: CSPort TAT1M2 Turntable
Brand: CSPort
SKU: 41131
Price: 39000.00 EUR
Availability: InStock

SKU: 41131 Category: Turntables Availability: Pre-order

39.000,00 €

Each LFT1M2 unit is configured as a stand-alone unit, allowing you to choose the one that best suits your environment.

The refined Japanese craftsmanship of the TAT1M2 turntable features a brass platter and granite base for superior stability and sound clarity. With an air-floating system, a servo-less motor, and a coreless motor drive, it delivers precise, vibration-free playback for audiophiles.

*The air supply and the tonearm attachment required to use this product are sold separately.

Available on backorder

Add to wishlist

Feel Safe Paying With

Excluding speakers & certain second hand items we offer:

Free Shipping in Greece for orders over 100€!
Free Shipping in Europe for orders over 1000€!
Free Shipping Worldwide for orders over 3000€!
Buy NOW with up to 24 Interest-Free Installments! (All Products are Eligible)

Description

The platter material has been changed from stainless steel to brass, following the previous model’s housing design of granite base, air float, and servo-less. With this change, even open-circuit type cartridges* using air-core coils are not affected by magnetic flux leakage, creating a quiet and expressive sound.

* Due to the open magnetic circuit and the powerful neodymium magnet used to secure the output, even non-magnetic stainless steel is magnetized, affecting the pickup of audio signals.

Highly rigid turntable

A heavy chassis with a granite base and brass platter suppresses micro vibrations from inside and outside the system. In addition, an air floating structure with a base and platter machined to a precision of 5μ, supports the 28kg platter with air pressure. By reducing the load on the bearings to only a few hundred grams, micro vibrations are suppressed.

Non-servo motor drive

Servo noise is eliminated by open control that does not apply a servo. In addition, a highly accurate voltage is supplied to the motor without fluctuation based on a crystal oscillator with high frequency accuracy. This unique “XFD System” technology allows the 28kg brass platter to rotate stably with a high moment of inertia.

Two arms expandability

Configurations can be selected to suit your system, such as using our Linear Arm AFU1-2, a swing arm, or two arms. Swing arm attachments are machined to fit the specified. Air Supply POU2 and various attachments (sold separately) are required for use.

Quiet air supply

The air supply is equipped with a highly reliable pump used in medical equipment to powerfully supply the volume required by the platter and linear arm. A double-sealed sound leakage and vibration prevention system keeps the system quiet enough to be installed in a listening room.

* Air Supply POU2 is sold separately

Specifications

Model	TAT1M2
	Material	Dimensions	Weight
Base	Granite Accuracy JIS0 class	358W×100H×358D mm	40 kg
Platter	Brass	φ344×43H mm	28 kg
Motor drive unit	Granite and Aluminum	130W×126H×358D mm	8 kg
Motor Control	Quartz oscillator, No-Feedback XFD system
Drive System	Thread drive (Aramid)
Motor	DC coreless low-noise motor
Turntable Speeds	33⅓, 45rpm
Rotation Precision	±0.3%
Wow	0.2% or less
Flutter	0.04% or less
Power Supply	AC100/120/200/240 V, 50/60 Hz
Power Consumption	40 W
Accessories	AC cord, Air tube, Drive thread, Level, Lubricating oil, Platter handle
Sold Separately	Player Board LPB1 or LPB2 Air Supply POU2 Linear Arm AFU1-2 Base Plate BPL1 Arm Attachment LAA1 or SAA1
Warranty Period	5 years

Air Supply POU2 (sold separately) is required for use.
Since the motor is not servo controlled, it takes time to reach a constant speed.
Due to the use of granite, the pattern and color tone of the stone may vary depending on the production lot.
Dimensions do not include legs, knobs, or terminals.
The descriptions are current as of March 31, 2023.
The appearance and specifications are subject to change without notice.
Actual colors may differ from those in the photographs due to photography, lighting, etc.
